mixer machine
this Plastic Raw Material Mixer Machine pvc powder mixer pvc powder high speed mixer apply to mix all kinds of plastic material with accessories of chemical additive agent .we have series of various plastic mixer unit , such as SRL-Z series mixer unit
This Plastic Raw Material Mixer Machine pvc powder mixer pvc powder high speed mixer is composed of two parts , hot mixing and cool mixing equipment , at same time ,it has drying function .
1.All the inner side contact with raw material are made of stainless steel material .
2.it’s well hermetic with a double sealed closure.
3.it has alternative heating ways for option , automatic and manual control
4.it has high automatic degree and is easy to operate , the raw material flows automatic in all the processing program
| model | Total volume | Dischargeable capacity | Thick liquid leaf rotational speed | Electrical machinery power | Water consumption | Ex-feeding way | External dimensions | Total quantity |
| SRL-Z100/200 | 100/200 | 75/160 | 650/1300 | 14/22/7.5 | 3.5t/h | Air operated | 2500X2000X2200 | 3T |
| /96 | ||||||||
| SRL-Z200/500 | 200/500 | 150/320 | 460/920/96 | 30/42/11 | 5 t/h | Air operated | 4580X2240X2470 | 3.5T |
| SRL-Z300/600 | 300/600 | 200/360 | 475/950/96 | 40/55/11 | 5.8 t/h | Air operated | 4580X2240X2500 | 3.8T |
| SRL-Z500/1000A | 500/1000 | 375/650 | 500/1000 | 47/67/15 | 6.9 t/h | Air operated | 4600X3000X4050 | 5.8T |
| /96 | ||||||||
| SRL-Z500/1600B | 500/1600 | 375/1200 | 500/1000 | 55/75/15 | 10 t/h | Air operated | 4600X3000X4050 | 7.3T |
| /68 | ||||||||
| SRL-Z800/1600A | 800/1600 | 600/1024 | 370/740/68 | 60/90/22 | 10 t/h | Air operated | 6230X4230X4480 | 8T |
| SRL-Z800/2000A | 800/2000 | 600/1500 | 370/740/68 | 83/110/22 | 12 t/h | Air operated | 4850X3860X6550 | 8.5T |
